GSO# 10323

DANVERS FD, MA
CHASSIS
  • 100” KME PredatorTM Severe Service XMFD with Flat Roof
  • Interior Cab Storage Compartment
DRIVE TRAIN
  • Cummins ISX12 500 hp Engine
  • Allison 4000 EVS Transmission
PUMP & TANK
  • Waterous CSU 2000 gpm Pump
  • UPF 300 Gallon Poly Water Tank
BODY
  • Hose Capacity 800’ of 4” LDH Minimum
  • Half Depth Adjustable Shelving, Slide OutFloor Mount Shelving, 500 lb, Rollout Tray, Roll-Our Dropdown Tray
  • Ground Ladder and Pike Pole Storage
ELECTRICAL
  • Harrison 10 kW Hydraulic Generator
  • Akron Brass Electric Cable Reel 225’ of 10 Gauge Electric Cable
  • Akron Brass Electric Cable Reel 200’ of Type
  • SO 10/4 Electric Cable
AERIAL
  • 1000lb. Dry/500lb. Wet Tipload
  • 18’ Jack Spread
  • -12° to ‘80° Elevation
  • 1/4″ Ice Rating
  • Floating Waterway Mount
  • 93’ Reach
  • 2.5 to 1 Structural Safety Factor
  • Iqan Motion Control System
  • Luminescent Rung Covers
  • Dual Monitor Water System 3000 GPM Rating
DIMENSIONS
  • Overall Height: 141”
  • Overall Length: 572”
  • Wheelbase: 254”
