GSO #10406

CLIFTON PARK - HALFMOON FD, NY
CHASSIS
  • Predator LFD Cab with 10″ Raised Roof
  • TOP Rollover Protection System with Slave Sensor
  • 10″ Front Bumper Extension
DRIVE TRAIN
  • Cummins ISX 15 600 HP Engine with Brake
  • Allison 4000 EVS Transmission
BODY
  • 3/16″ Aluminum AerialCat Body
  • 161′ Ground Ladder Compliment
  • Robinson Roll-Up Doors with Painted Finish
ELECTRICAL
  • Onan 8kw Mobile PTO/HYD Generator
  • One (1) Akron Brass 240v Electric Cord Reel
  • Optimo Rear Vision / GPS Camera System
  • Code 3 Lower Light Package
  • HiViz FireTech 46″ Scene Light at Rear of Body
AERIAL
  • 102′ AerialCat Rearmount Platform
  • 1000lb. Dry/500lb. Wet Platform Capacity
  • 18′ Jack Spread
  • -12 to +80 Degree Elevation
  • 1/4″ Ice Rating
  • Floating Waterway Mount
  • 94′ Vertical Reach
  • 2.5 to 1 Structural Safety Factor – 25% Stronger than NFPA requirements of 2 to 1 structural safety factor
  • IQAN Motion Control System
  • Photo-Luminesccent Rung Covers
  • Dual Monitor Water System 2000 GPM Rating
DIMENSIONS
  • Overall Height: 141″
  • Overall Length: 560″
  • Wheelbase: 254″
