GSO #10836-37

HAMILTON FD, ONTARIO
CHASSIS
  • Predator Severe Service 100″ LFD with 10″ Raised Roof Cab
DRIVE TRAIN
  • Cummins ISX 15 565 HP Engine
  • Allison 4000 EVS Transmission
PUMP & TANK
  • 500 Gallon Water Tank
BODY
  • 12GA Stainless Steel AerialCat Body
AERIAL
  • 103′ 4 Section AerialCat Ladder
  • 94′ Horizontal Wind Load Rating
  • 1/4″ Ice on Entire Structure
  • -8° to +80° Range of Motion
  • 2.5 to 1 Structrual Safety Factor
  • 500lb Top Load
  • 500lb Wet Tip Load Flowing 1500 gpm
DIMENSIONS
  • 472″ Overall Length
  • 232″ Wheelbase
  • 140″ Overall Height
